61-5180 Details

OEM Make: TVS
Part Number: 61-5180
Dimensions: 8.38 x 12.75 x 26
Outside Diameter: 12.75"
Length: 26.00"
Inside Diameter: 8.38"
Top: Open with a 14.25" x 16.00" flange
Bottom: Closed
Shape: Round
Approx. Square Footage of Filter Media: 222.64
Notes: The media for this TVS dust collector filter is 80/20 cellulose/polyester. (Select the 80/20 media option from the dropdown box above.) 80/20 is best to filter grinding dust, powder and dry chemical processing, and many other general manufacturing applications. Give us a call at (866) 393-0297 and we can help determine the proper filter media for your application.
